Here is a simple calculator model. Surfaces you see are all extruded and the rounded for smoothness. The buttons, the cuts for the mic and speaker have been made using the patterns command. Buttons could have two dimensions (vertically and horizontally) and an offset from a reference line, while the cuts for the speaker had just direction.
More detail could be added to this model by selecting the buttons as drawing planes and drawing numbers and finally extruding them a given height.
Time : 1 1/2-2 hours (I'm a beginner afterall!)
Done in Pro/E
